Keystone System

FF Series

Keystone modules compatible with Ekinex civil series. Wide range of devices to integrate network systems, multimedia systems and antenna systems with seamless architectural elegance.

Technopolymer: Pure White (RAL 9016) - GAR

EK-KSC-1K-GAA | EK-KSC-2K-GAA

Keystone System (55x55 mm Module)

Mounting adapter capable of integrating 1 or 2 RJ45, HDMI, USB and TV/SAT Keystone modules for square plates with standard 55x55 mm window.

Find out more Technical Documentation

Technopolymer: Pure White (RAL 9016) - GAR

EK-KSC-2K-GAA | EK-KSC-4K-GAA

Keystone System for 2-Fold Plate

Multiple mounting adapter supporting up to 2 or 4 Keystone modules for rectangular flush-mounting boxes and 2-fold plates.

Find out more Technical Documentation

Integrable Keystone Module Solutions

The Ekinex Keystone system aesthetically consolidates data communications, high-definition video transfer, smart device charging and audio/broadcast systems inside the standard 55x55 mm window module.

Network

RJ45 Cat. 6 / Cat. 6A Data Network

Shielded and unshielded connector support for high-speed local area networks (LAN), internet and IP automation infrastructure.

Audio / Video

HDMI Digital Multimedia

Direct transmission of 4K Ultra HD video and multi-channel audio signals from wall socket to displays or projectors.

Power & Charge

USB-A & USB-C Smart Fast Charging

Integrated dual-socket charging station for smartphones, tablets and mobile electronics.

Broadcast

TV-FM & SAT-F Broadcast Antenna

Impedance-matched coaxial connectors for terrestrial broadcast, cable TV and satellite antenna reception.

Sound

Audio & Speaker Terminals

Screw or spring terminals for multi-room audio, home cinema installations and high-fidelity sound speakers.

Numerous Customizations, Able to Meet the Most Different Needs

A wide range of devices is available to integrate network systems, multimedia systems and antenna systems. Standard dimensions allow easy snap-in mounting. They are completed with a square, double or triple plate with a 55 x 55 mm window, capable of housing one or more modules.
