Invisible Drywall

Description

Invisible Drywall is a top-quality acoustic energy transmitter designed to deliver outstanding performance and invisible sound transmission. Made from premium materials such as AW 6082 aluminum, chosen for its balance of precision, wear resistance through anodizing, and excellent heat dissipation, it ensures durability and reliability. Four internal nylon and steel suspensions ensure stability and flexibility over time, while triple thermal and electrical protection inside prevents failures, increasing operational safety.

Optimized for installation on walls or plasterboard ceilings up to 16mm thick, Invisible Drywall covers up to 80 square meters per single transmitter. For installations on vertical walls, the EK-VFX-AU accessory (purchased separately) provides fixation and durability while maintaining the necessary elasticity.

The completely invisible installation matches perfectly with the EK-PW1-AU amplifier, specifically designed to maximize system performance.

Functions and Features

Impedance4 Ω
Frequency Response40 - 14,000 Hz nominal
Maximum Power120 W
Maximum Power (RMS)40 W
Height46 mm
Diameter57 mm
Square Contact Plate80 mm per side
Weight330 g
ColorLight Bronze

Configuration and Commissioning

For proper installation, plan to use special adhesive EK-3M77-AU.

Connection Diagram

Ekinex Invisible Drywall Connection Diagram

Documentation and Downloads

Download official datasheets, installation instructions and certificates.

Instructions

FISPEKDW1AUIEX00 • PDF • 1.7 MB

Download

Accessories Instructions

FISPEKACCAUIEX00 • PDF • 1.5 MB

Download

CE Conformity Declaration

CEEKWALLPLAYER • ZIP • 926.9 KB

Download

UKCA Statement

UKCAEKDW1AU • PDF • 427.6 KB

Download

Technical Drawing (CAD)

DSEKDW1AU • DXF • 413.7 KB

Download
