R Series Loudspeakers

1960s Iconic Design, Contemporary Acoustic Technology

Product code: EK-R..

The 1960s Design Heritage, Contemporary Audio Fidelity

To relive the fantastic design of the ‘60s with contemporary technological solutions.

Deriving from the consolidated Q20 series, the R Series distinguishes itself with softer lines and rounded contours, evoking the sublime aesthetic of the 1960s while maintaining uncompromising acoustic performance.

Engineered to impress and satisfy discerning audiophiles, it conceals advanced electroacoustic technology behind a refined and understated design. It faithfully reproduces the entire audio spectrum down to the lowest registers with an expansive soundstage and deep spatial imaging.

R Series Models

Wall-mounted profile and tuned cubic volume designed to satisfy expert audiophiles.

R20 Wall-Mount Speaker

65 W RMS

EK-R20-W200 x 200 x 65 mm

Wall surface installation or bipolar flag mode with slim profile and gently curved edges.

Mounting style

Wall surface mount or bipolar flag bracket

200 x 200 mm rounded contour iconic retro form factor
Slim 65 mm depth for discreet architectural wall presence
65 W RMS power and 50 Hz - 21 kHz pristine frequency bandwidth
Ideal for executive offices, galleries, boutiques and fine residences

R20K Bookshelf / Surface Cube Speaker

80 W RMS

EK-R20-K200 x 200 x 200 mm

20 cm cube solid enclosure; 80W power and 45 Hz deep bass delivering an uncompromised full-range soundstage.

Mounting style

Freestanding placement on desk, console, credenza or bookshelf

Tuned 200 x 200 x 200 mm acoustic cube volume
80 W RMS robust output delivering articulate bass down to 45 Hz
Eliminates the need for a separate subwoofer in most residential spaces
Anti-resonance internal acoustic labyrinth and solid exterior

Colours and Finishes

The R Series shares the high-end finishing palette of the Q Series, combining machined metals and acoustic fabrics.

LBFrame

White Lacquer

LNFrame

Black Lacquer

ASAFrame

Satin Anodized Aluminium

ASNFrame

Black Satin Anodized Aluminium

BIFabric

White Fabric

NEFabric

Black Fabric

Ordering and Configuration Matrix

R Series order codes and installation variants configured for your project.

Series	Mounting	Variants	Frame	Fabric	Description	Dimensions
EK-R20	W (Duvar Yüzey)	ST / R (Bayrak)	LB, LN, ASA, ASN, LA	BI, NE, SA	Wall mount speaker, 65W, 50-21,000 Hz	200 x 200 x 65 mm
EK-R20	K (Serbest Küp)	ST	LB, LN, ASA, ASN, LA	BI, NE, SA	Surface mount cube speaker, 80W, 45-21,000 Hz	200 x 200 x 200 mm

Technical Specifications Comparison

Detailed electroacoustic parameters of R20W wall and R20K freestanding cube models.

Parameter	R20W (Duvar)	R20K (Küp)
Loudspeaker Type	Duvar Yüzey / Bayrak Dipol	Masaüstü / Kitaplık Küp
Nominal Power (RMS)	65 W	80 W
Frequency Response	50 Hz - 21.000 Hz	45 Hz - 21.000 Hz
Sensitivity (1W / 1m)	89 dB	89 dB
Impedance	8 Ω	8 Ω
Acoustic System	2 Yollu pasif bas refleks	2 Yollu akortlu pasif refleks
Transducers	Özel alaşımlı woofer + 25mm ipek kubbe	Yüksek salınımlı woofer + 25mm ipek kubbe
Dimensions (W x H x D)	200 x 200 x 65 mm	200 x 200 x 200 mm
Weight	2,7 kg	4,2 kg
Mounting Options	Duvar montaj braketi veya dipol bayrak	Titreşim sönümleyici ayaklı serbest zemin
