Dikdörtgen 3M Buat

4-Fold Basic Pushbutton for Rectangular Wall-Box (3-Module, NO LED)

EK-E23-TP-3M

4-fold basic KNX pushbutton without LEDs, dedicated to Italian standard 3-module rectangular boxes for lighting and automation management.

Finish & MaterialMetal HT - Gunmetal

Core Features

Italian Standard 3-Module Rectangular Box FitNO LED Uncluttered Functional ArchitectureScenario, Switching, and Dimming ExecutionAvailable in Metal, Technopolymer or Fenix NTM®

Made in Italy

9 Finishes Available

Architectural Integration & KNX Engineering

The 4-Fold Basic Pushbutton for Rectangular Wall-Box (3-Module, NO LED) (EK-E23-TP-3M) brings Ekinex's signature Italian geometric clarity and high-performance KNX bus automation into wall installations. Engineered for seamless flush-mounting across residential, hospitality, and commercial settings, it offers intuitive touch operation, advanced thermal control capabilities, and complete aesthetic coherence with Form, Flank, and 'NF frames.

Technical Specifications

Product Family: 71 Series Basic Pushbuttons (3M)
Design Line: Form or Flank 3-Module Frames
Mounting Standard: Italian standard 3-module rectangular box (83.5 mm fixing pitch)
Bus Connection: KNX bus terminal block (black/red)
Power Supply: 21-32 Vdc bus voltage, current consumption < 10 mA
LED Status Indicators: No LED Hardware (Basic Version)
